HPI25
High-Performance Dual 5″ LoudspeakerThe Quest HPI25 delivers a high-performance dual 5-inch configuration engineered for versatility and robust audio output. Its design enables applications ranging from stage infill and delay systems to front-of-house reinforcement, offering extended mid-bass performance and natural sound reproduction. A discreet “U” bracket mounting option ensures minimal visual impact while maintaining the series’ consistent sound signature, eliminating the need for extensive signal processing.
Key Specifications:
- Impedance: 8 Ω
- Transducers: 1″ HF & Dual 5″ LF
- Dispersion: 100° x 60°
- Power: 300W RMS
- Mounting: Wall/Ceiling/U
SPECIFICATIONS
| COLOURS |
|
||
| MODELS |
|
||
| FREQUENCY RESPONSE (-6 dB) |
60 Hz to 19 kHz |
||
| SENSITIVITY - 1 W @ 1 m |
92.5 dB |
||
| MAXIMUM SPL @ 1 m |
118 dB |
||
| POWER HANDLING (RMS/PEAK) |
240 W / 360 W |
||
| NOMINAL IMPEDANCE |
8 Ω |
||
| TRANSDUCERS |
HF: 25 mm (1") Compression Driver / 2 x LF: 127 mm (5") Woofer |
||
| DISPERSION (H° x V°) |
100° x 60° |
||
| ROTATABLE HORN |
YES |
||
| CONNECTIONS |
2 x speakON Connector (In/Thru) |
||
| RIGGING POINTS |
6 x M8 bolts (2 per side, 2 on top panel) |
||
| DIMENSIONS (H x W x D) |
432 x 182 x 150 mm (17" x 7.2" x 5.9") |
||
| WEIGHT |
9.3 kg (20.5 lb) |
||
| SHIPPING WEIGHT |
9.5 kg (21 lb) |
||
| SHIPPING DIMENSIONS (H x W x D) |
230 x 510 x 250 mm (9" x 20" x 9.8") |
||
| CABINET MATERIAL & FINISH |
Plywood Cabinet with Polyurea Coating |
||
| GRILLE MATERIAL & FINISH |
Perforated Steel Grille with Powder Coated Finish |
||
| RECOMMENDED POWER AMPLIFIER |
Quest QX Amplifiers |
||
| ACCESSORIES (INCLUDED) |
None |
||
| ACCESSORIES (AVAILABLE SEPARATELY) |
Wall Mount (UB1-OMA), Ceiling Mount (UB2-OMA), U Bracket (ACHPIUB25). |
INSTALLATION ACCESSORIES
UBOMA
Adaptor plate for UB1/UB2 mounts; required for HPI5/25/8, included with MX601/801.
Q Mount UB1
Wall mount with locking ball joint for MX601/801 and HPI speakers (with UBOMA adaptor).
Q Mount UB2
Ceiling mount for MX601/801 and HPI speakers (with UBOMA); features aim-and-clamp positioning.
UBHPI25
U-bracket for HPI25, suitable for vertical or horizontal wall/ceiling mounting.
