MX10S
Low Profile 10-Inch SubwooferThe Quest MX10S is engineered to provide extended low-frequency output within the MX Series, complementing higher-end installations that require pronounced bass performance. Featuring a custom-designed 10-inch woofer with a 50 mm voice coil and dual magnet configuration, the MX10S delivers robust and extended bass response suitable for commercial venues and distributed audio systems. It is available in low-sheen black or white finishes and is designed to integrate seamlessly with other series components, ensuring a balanced and visually coherent audio solution.
Key Specifications:
- Impedance: 8 Ω
- Transducer: 10″ LF
- Power: 300W RMS
- Mounting: Wall/Ceiling
- Design: Low Profile
SPECIFICATIONS
| COLOURS |
|
||
| MODELS |
|
||
| FREQUENCY RESPONSE (-6 dB) |
44 Hz to 90 Hz |
||
| SENSITIVITY - 1 W @ 1 m |
96 dB |
||
| MAXIMUM SPL @ 1 m |
118 dB |
||
| POWER HANDLING (RMS/PEAK) |
300 W / 500 W |
||
| NOMINAL IMPEDANCE |
8 Ω |
||
| TRANSDUCERS |
LF: 152 mm (10") Woofer |
||
| DISPERSION (H° x V°) |
Omnidirectional |
||
| CONNECTIONS |
Euroblock/Phoenix Connector - 5.08 mm Pitch (In/Thru) |
||
| DIMENSIONS (H x W x D) |
500 x 470 x 256 mm (19.6" x 18.5" x 10") |
||
| WEIGHT |
15.1 kg (33.3 lb) |
||
| RIGGING POINTS |
None |
||
| CABINET MATERIAL & FINISH |
Birch Plywood with Low Sheen Polyurea Paint |
||
| GRILLE MATERIAL & FINISH |
N/A |
||
| SHIPPING DIMENSIONS (H x W x D) |
520 x 520 x 320 mm (20.5" x 20.50" x 16.4") |
||
| SHIPPING WEIGHT |
15.5 kg (34.2 lb) |
||
| RECOMMENDED POWER AMPLIFIER |
Quest QX Amplifiers |
||
| ACCESSORIES (INCLUDED) |
Euroblock/Phoenix Connector |
||
| ACCESSORIES (AVAILABLE SEPARATELY) |
White Mounting Plate (MP10SW) and Black Mounting Plate (MP10SB) |
INSTALLATION ACCESSORIES
MP10S
Mounting plate for MX10S subwoofer, supporting wall or ceiling installations.
