MX6S
Low Profile 6-Inch SubwooferThe Quest MX6S is a compact subwoofer engineered to enhance the low-frequency performance of MX or MXC loudspeakers. Designed for permanent installations, it delivers a punchy yet smooth bass response that enriches commercial installations, hospitality environments, and similar professional spaces. Its custom 6-inch woofer, featuring a 38 mm voice coil and die-cast construction, ensures optimal performance in low to mid sound pressure level environments. Available in low-sheen black or white finishes, the MX6S integrates effortlessly into various interior designs while extending overall audio capabilities.
Key Specifications:
- Impedance: 8 Ω
- Transducer: 6″ LF
- Power: 100W RMS
- Mounting: Wall/Ceiling
- Design: Low Profile
SPECIFICATIONS
| COLOURS |
|
||
| MODELS |
|
||
| FREQUENCY RESPONSE (-6 dB) |
44 Hz to 90 Hz |
||
| SENSITIVITY - 1 W @ 1 m |
88 dB |
||
| MAXIMUM SPL @ 1 m |
106 dB |
||
| POWER HANDLING (RMS/PEAK) |
100 W / 200 W |
||
| NOMINAL IMPEDANCE |
8 Ω |
||
| TRANSDUCERS |
LF: 152 mm (6") Woofer |
||
| DISPERSION (H° x V°) |
Omnidirectional |
||
| CONNECTIONS |
Euroblock/Phoenix Connector - 5.08 mm Pitch (In/Thru) |
||
| DIMENSIONS (H x W x D) |
169 x 361 x 361 mm (6.6" x 14.2" x 14.2") |
||
| WEIGHT |
6 kg (13.2 lb) |
||
| RIGGING POINTS |
None |
||
| CABINET MATERIAL & FINISH |
Birch Plywood with Low Sheen Polyurea Paint |
||
| GRILLE MATERIAL & FINISH |
N/A |
||
| SHIPPING DIMENSIONS (H x W x D) |
240 x 415 x 415 mm (9.5" x 16.4" x 16.4") |
||
| SHIPPING WEIGHT |
7.1 kg (15.6 lb) |
||
| RECOMMENDED POWER AMPLIFIER |
Quest QX Amplifiers |
||
| ACCESSORIES (INCLUDED) |
Euroblock/Phoenix Connector |
||
| ACCESSORIES (AVAILABLE SEPARATELY) |
White Mounting Plate (MP6SW) and Black Mounting Plate (MP6SB) |
INSTALLATION ACCESSORIES
MP6S
Mounting plate for MX6S subwoofer, allowing secure wall or ceiling installation.
