MX801
High-Fidelity 8″ Weatherproof LoudspeakerBuilding on the robust engineering of the MX601, the Quest MX801 is an 8″ weatherproof surface mount speaker designed for both indoor and outdoor installations. It delivers enhanced audio performance in a durable enclosure, ensuring reliable operation under challenging environmental conditions. The MX801’s rugged construction and efficient mounting system provide consistent, high-fidelity sound, making it a dependable solution for professional applications where durability and performance are paramount.
Key Specifications:
- Impedance: 16 Ω
- Transducers: 1″ HF & 8″ LF
- Transformer: 70/100V integrated
- Dispersion: 150° x 120°
- Power: 100W RMS
- Weather Rating: IP67 (with IPMX1 Kit)
SPECIFICATIONS
| COLOURS |
|
||
| MODELS |
|
||
| FREQUENCY RESPONSE (-6 dB) |
75 Hz to 20 kHz |
||
| SENSITIVITY - 1 W @ 1 m |
93 dB |
||
| MAXIMUM SPL @ 1 m |
112 dB |
||
| POWER HANDLING (RMS/PEAK) |
100 W / 200 W |
||
| NOMINAL IMPEDANCE |
16 Ω |
||
| TRANSDUCERS |
HF: 25 mm (1") Dome Tweeter / LF: 203 mm (8") Woofer |
||
| DISPERSION (H° x V°) |
150° x 120° |
||
| TRANSFORMER SETTINGS |
100 V: 20 W / 30 W / 40 W / 60 W 70 V: 10 W / 15 W / 20 W / 30 W |
||
| CONNECTIONS |
Euroblock/Phoenix Connector - 5.08 mm Pitch (In/Thru) |
||
| DIMENSIONS (H x W x D) |
345 x 202 x 243 mm (13.5" x 7.9" x 9.6") |
||
| WEIGHT |
4.3 kg (9.5 lb) |
||
| RIGGING POINTS |
2 x M6 rigging points on sides |
||
| IP RATING |
Speaker Cabinet IP56 (IP67 when used with IPMX1 Kit) |
||
| CABINET MATERIAL & FINISH |
Injection Moulded ABS Plastic |
||
| GRILLE MATERIAL & FINISH |
Perforated Powder Coated Aluminum |
||
| SHIPPING DIMENSIONS (H x W x D) |
250 x 430 x 420 mm (9.8" x 16.9" x 16.5") |
||
| SHIPPING WEIGHT |
7.2 kg (15.87 lb) |
||
| RECOMMENDED POWER AMPLIFIER |
Quest QX Amplifiers |
||
| ACCESSORIES (INCLUDED) |
UB1 Wall Mount Bracket |
||
| ACCESSORIES (AVAILABLE SEPARATELY) |
Ceiling Mount Bracket (UB2) and Weatherproof Gland (IPMX1) |
INSTALLATION ACCESSORIES
UBOMA
Adaptor plate for UB1/UB2 mounts; required for HPI5/25/8, included with MX601/801.
Q Mount UB1
Wall mount with locking ball joint for MX601/801 and HPI speakers (with UBOMA adaptor).
Q Mount UB2
Ceiling mount for MX601/801 and HPI speakers (with UBOMA); features aim-and-clamp positioning.
IPMX1
Weatherproofing kit enabling IP67 rating for outdoor MX Series installations.
